A surrogate-based optimal likelihood function for the Bayesian calibration of catalytic recombination in atmospheric entry protection materials

Anabel del Val, Olivier P. Le Maître, Olivier Chazot, Thierry E. Magin, Pietro M. Congedo

  • Engineers still grapple with understanding the physical phenomena involved during the atmospheric entry of space capsules. So far, this severe lack of knowledge has been overcome in practice by over-doing safety measures, not too engineering-like if you ask me. Since the 60s, the community has been trying to gather knowledge on what happens to the space vehicle’s surface when it enters dense planetary atmospheres. We still don’t have a comprehensive answer but we are better suited to understand it. The problem is that many things happen at the same time. It is difficult (at least with current technology) to test separately each little phenomenon occurring during atmospheric entry or even to design tests where you isolate one effect: thermal behavior of the gas, chemistry, etc.

    When we test to learn about different phenomena, we can only measure quantities that are a final effect of a bunch of different things. If you want to learn about chemical reactions in the gas, you have to assume many things about that gas, the experimental data is not enough. This way, you will always get partial understanding and highly dependent on the assumptions made and conditions tested. The work I present here contains 3 different contributions for the community:

    1) The 2 most immediate causes that could explain the experiments on reusable protection materials are considered not known at the same time, even though we only want to learn about one of them. We need this in order not to bias the result with a hard assumption.

    2) The cause we are not interested in (contribution of the convective heat flux to the overall heat flux the protection material experiences) is limited to its most likely values thanks to the mathematical framework we developed, reducing the uncertainty on the cause we are interested in (contribution of the diffusive heat flux).

    3) We show that it’s possible to improve the experiments in a plasma wind tunnel to increase our certainty about the value of the parameter of the cause we are interested in (catalytic efficiency), vital for the community as it’s embedded in all CFD simulations of this kind.

    This contribution is only an idea in a very promising research direction that we are exploring in my PhD. Stay tuned!

Experimental methodology for the accurate stochastic calibration of catalytic recombination affecting reusable spacecraft thermal protection systems.

Anabel del Val, Diana Luís, Olivier Chazot

  • In the previous work, we asked ourselves the question: can we find the needle in this huge haystack? The needle being catalytic recombination parameters and the haystack being all the different physical processes affecting the heat flux experienced by the material exposed to the plasma flow. We investigated a Bayesian methodology to be able to confidently pinpoint the effect of catalytic recombination on the observations (heat flux). Now we pose the following question: can we increase the confidence in knowing we found the good needle by changing the haystack where the needle is hidden? In other not-so-metaphoric words, can we condition the physics of the experiments so much that we can be very certain about the parameters obtained? To do this, we looked at experimental methodologies that add certainty and constraints to our models of choice together with Bayesian analysis tools.

    The work I present here contains 2 different contributions for the community:

    1) We guide the design of the experimental methodology with stochastic analyses, looking for reduction of uncertainty on the sought out parameters. This is a first in the aerothermodynamics literature where deterministic methods are still used to solve inverse problems. The deterministic nature of the problem prevents the evaluation of uncertainty on the results and, as a consequence, the information coming from the experiments cannot be properly assessed, resulting in experimental cases that bring little or no information to the catalytic parameters. In other words, the haystack is so large that anything can resemble the needle we are looking for.

    2) This work delivers the first catalysis database with accurate uncertainty estimates in the aerothermodynamics literature. Furthermore, it guides the production of high-quality wind tunnel data for validation purposes by greatly increasing the certainty on the computed parameters such that we do not need to make assumptions about them. The more informative our experiments are, the more useful are the data to increase the confidence in our tools or, conversely, invalidate our models, finding the limits of validity with high certainty.
